Introduction:
JRF 1120-C activated coalescing filter is a specialized coalescing filtration mechanical component. JRF series activated carbon coalescer filter is mainly used in oil and gas coalescing purification and filtration equipment systemshydraulic systems to filter out solid particles and colloidal substances in the working medium, effectively Control the pollution degree of the working medium to achieve the effect of purifying the medium.
More JRF Series:
JRF 720-C
JRF 1120-C
JRF 1122-C
JRF 1122-C-2.25
JRF 1122-C-N
Technical Parameters:
| Item | Data |
|---|
| Length | 20.0 inches |
| Outside Diameter | 10.75 inches |
| Innerside Diameter | 2.06 inches |
| Flow Direction | Radial, outside-to-inside |
| Max. Differential Pressure | 90 psid / 6.2 bar |
| Max Temp | 300ºF / 149ºC |
| Recommended Flow Rate | 1.3 gpm / 4.92 lpm per canister |
| Carbon | Granular Activated Carbon 8x30 mesh |
Structural Components:
We make JRF 1120-C coalescers cartridge filter outer structure and central tube are made of corrosion-resistant steel and have an exoskeleton structure. All filters can withstand 145 psid pressure, have high performance, improve efficiency, keep the fluid clean, and ensure that the coalescing purification filtration equipment systemhydraulic system operates more smooth.
Filter Material:
Our manufactured JRF 1120-C coalescing filters use a single unit structure to reduce the number of gaskets and improve overall reliability. JRF 1120-C coalescers cartridge filter have one or more layers of pleated media inside molded fiberglass laminated cylinders to provide a larger particle filtration surface area. Use pleated ripples and separate materials to keep the pleats open for full use.
• The composite glass fiber and fold medium coalescers mainly remove particles from high surface area fold cores.
• All glassfiber media aggregator combines deep particle filtration with deep coalescence structure.
• The all-glass fiber design has a continuous thinner dielectric layer to achieve deep filtration of particles.
Test Standards:
Before delivery, Our manufactured JRF 1120-C coalescer cartridge will be tested and follow the standards:
ISO 2941 Collapse & Burst Resistant
ISO 2942 Fabrication & Integrity Test
ISO 2943 Material Compatibility with Fluids
ISO 3724 Flow Fatigue Characteristics
ISO 3968 Pressure Drop vs. Flow Rate
ISO 16889 Multi-pass Performance Testing
Customized Processing:
We corporation are excellent coalescer cartridge filter manufacturer
Parker & Velcon
PECO & Facet
Faudi
Pall
Other types are available on request.
JRF 1120-C JRF Series Radial Flow Activated Carbon Canister Filter
