Introduction:
AC-21005 is mainly used to remove water and dirt from oils,fuels and gases. We make AC-21005 has a special construction for removing dirt and water from hydrocarbon and other oils as well as gases.It can reache the coalescer function.The outer media layer filters out silt,rust and other particulate contaminants.The inner layers absorb water and chemically bond it so that no water will release downstream.
Performance Parameters：
| Item | Value |
|---|
| Length | 9.75 inches |
| Outside Diameter | 2.63 inches |
| Inside Diameter | 1.0 inches |
| Filtration accuracy...... | 99.9% |
| pH range | 4 - 9 |
| Max Temperature | 200°F |
| Filter Material | Micro Fiberglass and Cellulose, Pleated Paper |
| Seal | Buna-N |
| Removal Effciency | Effuent solids <0.15 mg/liter |
| Center Tube | Corrosion Resistant Steel |
More AC Series
AC-60925, AC-71825, AC-73601, AC-73605, AC-815P3, AC-815P4D, AC-718P4D, AC-O61405C, AC-O21001B, AC-82901, AC-O61401K, AC-I44001C
AC-21005, AC-71805, AC-7181/2, AC-80701, AC-8071/2, AC-81501, AC-8151/2, AC-82201, AC-8221/2, AC-71901CR, AC-71825, AC-822P3, AD512225
AC-82205, AC-51225, AC-51225, AC-51205, AC-51205C, AC-71801, AC-I65601CTB, AC-O51201B, AC-O51201C, AC-O51205B, AC-61405, AC-A210
AH511P8SP, AC-051205C, AC-I64401DTB, AC-7361/2, AC-I63301CTB, AC-I63301LTB AD20125, AC-0512050, AC-718P3 , AD21025, AC-O51201K
Filter Material:
Our manufactured AC-21005 pleated water filter cartridge media is made from high quality hydrophobic pleated cellulose material. The outer media layer filters out silt, rust and other particulate contaminants, while the inner layer absorbs water and chemicals. AC-21005 filter element is widely used in various industrial industries such as power generation, oil and gas, petrochemicals, aerospace, etc.
• All metal parts are treated for corrosion protection
• Composite fiber and pleated paper media high surface area pleated core.
• Buna-N gaskets - other materials available upon request
Material Properties:
Our manufactured AC-21005 water asorbing filter cartridge media is made from high quality hydrophobic pleated cellulose material. The outer media layer filters out silt, rust and other particulate contaminants, while the inner layer absorbs water and chemicals. AC-21005 filter elements are widely used in various industrial industries such as power generation, oil and gas, petrochemicals, aerospace, etc.
Test Standards:
Before delivery, Our manufactured AC-21005 filter cartridge will be tested and follow the standards:
ISO 2941 Collapse & Burst Resistant
ISO 2942 Fabrication & Integrity Test
ISO 2943 Material Compatibility with Fluids
ISO 3724 Flow Fatigue Characteristics
ISO 3968 Pressure Drop vs. Flow Rate
ISO 16889 Multi-pass Performance Testing
AC 7181/2 Applications:
Gasoline
Transformer Oil
Synthetic Oil
Kerosene
Hydraulic Oil
Phosphate Ester Oil
Diesel Fuel
Turbine Lube Oil
Instrument Air
Insulating Oil
Quench Oil
Process Gases
AC-21005 Parker Velcon AC Series Water Absorbing Cartridge Replacement
